Arrow 20 x 29 x 7 ft Eggshell Carport
Model #: CPH202907
In stock
SALE!
$5,499.99CAD
$4,399.99CAD
Free Shipping
Arrow Carports Galvanized Steel Carport, Double Car Metal Carport Kit, 20' x 29' x 7', Eggshell
Warranty: 10 Year Limited
Manufactured in USA
Do you have questions about this product? Our Customer Service team is here to help!
Product Overview
Built strong, wind and snow rated, and backed by a 10-year limited warranty is the Arrow Carport. This galvanized steel carport from Arrow Storage Products features a powder coated steel frame for corrosion and rust resistance. The tough made galvanized steel roof is made strong. Perfect for use as a carport, shelter, shade and storage for boats, vehicles, tractors and even as an outdoor picnic area.
- 20 x 29 ft. All-Steel Carport
- Built strong with a 2 in. square tube, 15 gauge wall thickness. The Arrow Carport delivers wind and snow load strength and stability.
- Black powder coated finish for superior rust and corrosion resistance.
- Designed for easy installation thanks to slip-fit connections with pilot holes and self-drilling screws.
- Tough, horizontal roof-panels made from 29-gauge galvanized steel for superior corrosion resistance.
- Attractive eggshell roof with a black, powder coated frame.
- Perfect for car storage and shelter, truck shelter, vehicle shelter, boat shelter or as a multi-use shade and picnic area.
- Wind and snow loads given are for reference only and assume a standalone unit without enclosure kit, and a securely anchored frame and unit according to local building codes and ordinances. These have been calculated using combined snow and wind load provisions in accordance with ASCE 7-05. These calculations are based on an unoccupied structure. Local building code requirements vary by location; conformance to local codes is the responsibility of the purchaser.
Manuals
Additional Resources
Specifications
| Product Details | |
|---|---|
| SKU | CPH202907 |
| Specifications | |
| Assembly Manual | Download (PDF) |
| Size | 20 x 29 x 7 ft. |
| Details | |
| Manufacturer | Arrow Storage Products |
| Series | Arrow Carport |
| Roof Type | Peak |
| Material | Galvanized Steel |
| Color | Eggshell |
| Frame Color | Black |
| Assembly Required | Yes |
| Included Items | Roof Panels, Frame, Anchors, Hardware, Instructions |
| Dimensions | |
| Width | 20 ft. |
| Length | 29 ft. |
| Height | 7 ft. |
| Total Storage Area | 567 sq. ft. |
| Total Storage Volume | 4701 cu ft |
| Assembled Exterior Dimensions Width | 20 ft. 3 in. |
| Assembled Exterior Dimensions Depth | 28 ft. 7 in. |
| Assembled Exterior Dimensions Height | 9 ft. 8 in. |
| Assembled Interior Dimensions Width | 19 ft. 8 in. |
| Assembled Interior Dimensions Depth | 28 ft. 7 in. |
| Assembled Interior Dimensions Height | 9 ft. 6 in. |
| Door / Entrance Height Outside | 84 |
| Wall Height | 7 ft. |
| Peak Height | 9 ft. 8 in. |
| Warranty/Certifications | |
| Warranty | 10 Year Limited |
| Wind Speed Rating | 100 MPH |
| Snow Load Rating | 171 |
| Water-Resistant | Yes |
